PLQ-22CS Passbook Printer
(BROTHER)
Enjoy operational efficiency with its first multi-function passbook printer and scanner, PLQ-22CS a secure solution that offers space, time and cost savings for your business.
High-speed efficiency for multiple functions
Speed: up to 480cps (10cpi)
High-speed duplex colour scanner for optimum security
Reliable High Recognition Magnetic-ink Character Reader (MICR)
Scanning
• Document Feed
Scanner Type
• Document Feed
Sensor Type
• CIS
Maximum Scan Area
• 216 × 356 mm
Output Resolution
• Main: 600 dpi / 300 dpi / 200 dpi
• Sub: 600 dpi / 300 dpi / 200 dpi
Scanner Bit Depth (Colour)
• Input: 24-bit
• Output: 24-bit
Scanner Bit Depth (Black & White)
• Input: 8-bit
• Output: 8-bit
Max Document Size
• 216 × 356 mm
Print Characteristics
Character Sets
• International
• PC-437 International
Barcode
• EAN-13
• EAN-8
• Interleaved 2 of 5
• UPC-A
• UPC-E
• Code 39
• Codabar (NW-7)
• Industrial 2 of 5
Paper Path
Manual Insertion
• Front In, Front Out
• Front In, Rear Out
Paper Media
Cut Sheet (Single Sheet)
• Width: 65 – 245 mm (2.6" – 9.6")
• Length: 67 – 297 mm (2.64" – 11.69")
• Thickness: 0.065 – 0.19 mm (0.0025" – 0.0074")
Cut Sheet (Multi-part Forms)
• Width: 65 – 245 mm (2.6" – 9.6")
• Length: 67 – 297 mm (2.64" – 11.69")
• Thickness: 0.12 – 0.53 mm (0.0047" – 0.021")
Passbook
• Width (Horizontal): 110 – 241.3 mm (4.33" – 9.5")
• Width (Vertical): 110 – 241.3 mm (4.33" – 9.5")
• Length (Horizontal): 127 – 220 mm (5.0" – 8.66")
• Length (Vertical): 85 – 220 mm (3.35" – 8.66")
• Thickness: Max. 2.6 mm
• Cover Page: 0.2 – 0.5 mm
• Each Page: 0.1 – 0.15 mm
Total Thickness
• 2.6 mm
Consumables
Ribbon Cartridge (Black)
• Approx. 5 Million Characters (LQ 10 CPI, 48 Dots/Character)
• Approx. 10 Million Characters (Draft 10 CPI, 24 Dots/Character)
Environmental Conditions (Operating)
Temperature
• 5°C – 35°C (Without Condensation)
Humidity
• 10% – 80% RH (Without Condensation)
Acoustic Noise
• Approx. 55 dB(A) – A4 Single Sheet
• Approx. 53 dB(A) – Passbook
Input Data Buffer
• 128 KB
High-speed efficiency for multiple functions
Process cheques speedily with this multi-function device that reads magnetic characters on cheques, prints, and scans both sides of a cheque simultaneously. With an optical resolution of 600dpi and ultra-high scanning speed of up to 20 ips, processing time is cut down significantly.
Save space, time and cost with digitisation
Digitisation helps to reduce the cost of storing and transporting paper cheques. Enjoy greater space and cost savings as no other separate MICR readers or scanners are required. Combined with functions like the ID Photo card scan and Magnetic Reader/Writer (MSRW), this device will be of great use to all your front desk operations.
